Linear Voice Coil Motor Actuator LVCM-013-025-02, Continuous Force: 2.9 Oz (0.79 N), Stroke: 0.75 in (19.1 mm)

The LVCM-013-019-02 (Imperial version) and the LVCM-013-019-02M (Metric version) Linear Motors feature low inertia and high acceleration/deceleration.

Two brushless high speed linear servo motors with a 0.75 in (19.1 mm) long stroke, have a high-force-to-size ratio of 2.9 oz (0.81 N) and a peak force of 9.0 oz (2.51 N) at a 10% duty cycle. Operated in a closed loop as a DC Servo Motor, these miniature linear servo motors have high accuracy and high repeatability, and are clean, quiet, reliable, and efficient.

The LVCM-013-019-02 and the LVCM-013-019-02M Linear Voice Coil Servo Motors are also known as moving coil motors or linear actuators, is 1.156 in (30.2 mm) long at mid-stroke. These high force-to-size linear servo motors are ideal for: Scanners, laser beam steering and filtering, haptic feedback, dynamic vibration absorption, dispensing, work holding and clamping, assembly, testing, and wafer handling.
